3.0.2 Dolby Atmos with a touchscreen and wireless growth to 5.1.2
WiiM Bar combines eight active drivers, four passive radiators, HDMI eARC and WiiM streaming in a 135 W soundbar with dedicated height channels.
The single WiiM Bar starts as a true 3.0.2 system: three mid-woofers and three tweeters cover the front, while two upward-firing full-range drivers handle height effects. A circular 2.1" touchscreen adds local information and control, and the architecture can expand wirelessly with compatible surrounds and a subwoofer to reach 5.1.2.
Key features
- Native 3.0.2 layout with Dolby Atmos and DTS:X support
- Eight active drivers plus four passive radiators in the cabinet
- 135 W total system power
- 2.1" front touchscreen for sources, EQ, presets and album art
- HDMI eARC with LPCM, Dolby TrueHD, Dolby Digital Plus, AC3 and DTS
- Wi-Fi 6E, Ethernet and Bluetooth 5.4
- Optical and Line In connections plus USB Audio In/Out and USB Host
- RoomFit, Clear Voice, AI Dialog Enhancement and Night Mode
Not merely a stereo soundbar using virtual processing
The two top-firing transducers are physical height channels and work with the six front drivers to create the 3.0.2 layout. Dolby Atmos and DTS:X are therefore reproduced through a genuinely multi-channel acoustic architecture inside the bar rather than starting from only two principal loudspeakers.
From television sound to network music
HDMI eARC carries compatible home-theatre formats from the TV and makes the display the main source when required. For music, WiiM Home is joined by Google Cast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, LMS and Roon, allowing Bar to operate as an independent streaming zone.
The 2.1" display is part of the user interface
The circular panel shows artwork, track information and sources while providing quick access to playback, EQ and Smart Presets. The supplied WiiM Bar Voice Remote adds a rechargeable battery and Push-to-Talk Alexa, while an external Alexa or Google Home device can handle compatible voice commands.
Expand when the room calls for more immersion
The soundbar can remain a self-contained 3.0.2 system or become the centre of a 5.1.2 layout by adding wireless rear speakers and a supported subwoofer. RoomFit adapts playback to the room, while Clear Voice, AI Dialog Enhancement and Night Mode address speech clarity, dense dialogue and lower-volume viewing as separate listening needs.
