General Overview
The Velodyne Acoustics MiniVee X is an ultra-compact subwoofer with advanced technology to deliver exceptional performance in a small space.
The closed cabinet offers unparalleled accuracy while minimizing unwanted resonances.
The combination of an active driver and an 8" passive radiator delivers powerful, accurate bass with minimal cabinet movement. Automatic room optimization is quick and easy with the Velodyne Acoustics Auto EQ app and included microphone, allowing for custom calibration and optimal acoustics.
Main Features
-
App Control : The Velodyne Acoustics Auto EQ app, available on the Apple Store and Google Play, makes it easy to set up and automatically calibrate your subwoofer. Numerous adjustments can be made to customize the sound to your individual preferences.
-
Ultra-compact design : The compact, reinforced MDF cabinet eliminates unwanted resonances, ensuring clean, precise sound.
-
High Power : With Class D amplification reaching up to 800W of maximum power , supported by oversized ferrite magnets, the MiniVee X delivers deep, punchy bass.
-
Versatile Connections : Featuring RCA, XLR inputs, and speaker terminals, the MiniVee X easily adapts to any audio setup.
Acoustic Performance
The Velodyne MiniVee X delivers a premium audio experience through the use of proprietary next-generation drivers.
Its compact design does not sacrifice sound quality, which is always powerful and precise, perfect for small spaces but capable of satisfying even lovers of deep bass.
Design and Construction
The high-density MDF cabinet with a high-gloss black finish is not only aesthetically elegant, but is designed to reduce vibrations and internal resonances . The subwoofer combines cutting-edge technological performance with a compact and discreet design, suitable for any home environment.
Advanced Features
The Velodyne MiniVee X is equipped with the latest technologies, including automatic room acoustic calibration via the included microphone and dedicated app, which allows for effortless optimization.
This makes the MiniVee X an ideal product for those looking for deep, precise bass in a compact format, with the convenience of remote control via smartphone.
Technical Specifications
Driver
|
Proprietary 8" long-throw driver with 8" passive radiator |
Amplification
|
Class D, 350W RMS @ 0.5% THD, 600W @ 2% THD, 800W maximum |
Frequency response (±3 dB)
|
32Hz – 180Hz |
Overall frequency response
|
18Hz – 300Hz |
Low-pass crossover
|
30 Hz – 200 Hz with a slope of 12 dB per octave |
Phase
|
Adjustable from 0 to 180 degrees |
Magnets
|
Double ferrite magnet motor |
Moving coil
|
2" voice coil with high purity copper windings |
Entrances
|
Unbalanced stereo RCA, balanced stereo XLR, 3.5mm mini-jack, 5V USB |
Exits
|
Unbalanced stereo RCA, balanced stereo XLR, 3.5mm mini-jack |
Dimensions (H x W x D)
|
30cm x 29cm x 29cm |
Weight
|
15 kg |
Shipping weight
|
20 kg |
Finish
|
Glossy black |
