Uncompromising Audio Quality
Welcome to the world of high-resolution audio, where our DAP digital player offers unparalleled audio quality. Supporting files up to 32bit/384KHz , including ALAC, APE, AAC, FLAC, OGG, AIFF, DFF, DSF, WAV, WMA, and MP3 , our DAP is the answer to the needs of the most demanding audiophiles.

Format Versatility and DSD Support
From ALAC to MP3, our DAP can handle a wide range of audio formats. The ability to play native DSD 256 and 11.2 MHz files takes the listening experience to a new level. Additionally, support for MQA files and Roon Ready certification further expand your playback options.

Power and Precision in the Palm of Your Hand
Equipped with a super-fast quad-core CPU, our DAP delivers power and precision . The internal Cirrus Logic CS43198 MasterHIFI™ quad DAC offers unprecedented flexibility , with the ability to select either Dual or Quad operation.

Wide Connection, Wide Choices
With separate Next Generation Amp amplifiers and Teraton Alpha technology , you can customize your listening experience by selecting two gain settings, normal and high. The 64GB internal memory, expandable up to 1TB via a microSD slot , ensures there's room for your music library.

Intuitive Visualization
Enjoy a crisp visual experience on the 3.6" TFT LCD touchscreen display with 720x1080 resolution. The new Crimson theme graphical interface makes using the device even more intuitive.

Connection Without Limits
With dual-band Wi-Fi and DLNA streaming via the AK Connect App , our DAP offers seamless connectivity. Bluetooth 5.0 aptX HD and LDAC technology, along with the versatile headphone output, satisfy all your connection needs.

Extended Autonomy
Thanks to the internal lithium-polymer battery, our DAP offers an exceptional 21 hours of battery life. Power and charging are provided via microUSB cable, ensuring convenience and flexibility.
Elegant Design, Total Compatibility
Featuring an aluminum chassis , our DAP not only delivers high-quality performance but also features an elegant design. Compatibility with the AMP, Cradle, CD Ripper, Recorder, and Remote models further enriches your audio experience.
Perfect Portability
With compact dimensions (64x108.3x16.1mm) and a weight of only 184gr , our DAP is designed to offer portability without compromise.
Explore an unprecedented listening experience with our High-Resolution Digital Audio Player (DAP).
Technical data sheet
| Audio Resolution |
Up to 32bit/384KHz |
| Playable Audio Formats |
ALAC, APE, AAC, FLAC, OGG, AIFF, DFF, DSF, WAV, WMA, MP3 |
| DSD support |
Native at 256 and 11.2MHz |
| MQA support and Roon ready |
Yes |
| CPU |
Ultra-high-speed quad-core |
| Internal DAC |
Quadruple Cirrus Logic CS43198 MasterHIFI™ DAC, selectable in Dual or Quad mode |
| Amplifiers |
Separate Next Generation Amp, Teraton Alpha technology, selectable normal and high gains |
| Internal Memory |
64GB, expandable up to 1TB via microSD slot |
| Display |
3.6" TFT LCD touchscreen, 720x1080 resolution |
| Graphical Interface |
New Crimson theme graphical interface |
| Wireless Connections |
Dual band Wi-Fi, DLNA streaming via AK Connect App |
| Bluetooth connection |
Bluetooth 5.0 aptX HD, LDAC |
| Audio Output |
3.5mm headphone jack, dual 2.5mm and 4.4mm 4-pole balanced output |
| USB connection |
USB audio out, USB-C input (PC/Mac and MTP data transfer) |
| Power and Charging |
MicroUSB cable, Internal 3.8V 5050mAh lithium polymer battery with 21 hours of battery life |
| Chassis |
Aluminum |
| Compatibility |
AMP, Cradle, CD Ripper, Recorder and Remote models |
| Dimensions (WxHxD) |
64x108.3x16.1mm |
| Weight |
184gr |
