Lyngdorf TDAI-1120: digital integrated amplifier with streaming and RoomPerfect
The TDAI-1120 brings amplifier, network player and room correction together in a compact case. Amplification is Class D with Equibit technology, which keeps the signal digital up to the power stage, and delivers 60 W per channel into 8 Ohm and 120 W into 4 Ohm. It runs cool and can also be placed inside a cabinet.
RoomPerfect measures the room at several points with the supplied microphone and adapts the response of the speakers to the space; the same processor manages an optional active subwoofer with an adjustable digital crossover. Music arrives over Wi-Fi and Bluetooth with Spotify Connect, Tidal Connect, Chromecast, AirPlay 2, Roon Ready, UPnP and DLNA, while the HDMI eARC connection carries the sound of the television and lets its remote set the volume. For a turntable there is an MM phono input. Everything is controlled from the Lyngdorf app or from a browser.
Technical features
- Power: 2 x 60 W into 8 Ohm, 2 x 120 W into 4 Ohm
- Digital inputs: 2 coaxial up to 192 kHz and 24 bit, 2 optical up to 96 kHz and 24 bit, HDMI eARC
- Analogue inputs: line on RCA and MM phono on RCA
- Analogue output: stereo RCA pre-out
- Network: Wi-Fi, RJ45 Ethernet, Bluetooth, USB Type A port for local files
- Frequency response: from 20 Hz to 20 kHz within 0.5 dB
- Control: app for iOS and Android, web interface, IP, CEC, trigger in and out
- Dimensions with connectors: height 10.1 cm, width 30 cm, depth 26 cm
- Weight: 3.3 kg
