Fyne Audio F5E LCR: 2.5-way LCR speaker built around a 125 mm IsoFlare driver
The Fyne Audio F5E LCR is a home theatre speaker that can serve as the left, centre or right channel. Fyne Audio presents it as a building block for a first home cinema system, with intelligible dialogue and involving effects. It is sold singly.
The small cabinet holds a 125 mm IsoFlare point source unit, in which a multi-fibre cone covers bass and midrange and a 19 mm titanium-dome compression tweeter sits at its centre, together with a 125 mm bass driver and a passive radiator (ABR) of equal size. Built-in brackets allow the speaker to be fixed to a wall; alternatively it can simply stand on a surface.
Key features
- 2.5-way system assisted by an auxiliary bass radiator (ABR)
- 125 mm IsoFlare driver with a 19 mm titanium compression tweeter
- 125 mm bass driver plus a 125 mm ABR
- Frequency response 65 Hz - 38 kHz (-6 dB, typical in-room figure)
- Sensitivity 88 dB (2.83 V at 1 m), nominal impedance 8 ohm
- Suggested amplifier output from 30 to 100 W RMS
Technical data
The crossover points are 350 Hz and 1.8 kHz, using a second-order low-pass section and a first-order high-pass section. Continuous power handling is 50 W RMS. The speaker measures 170 x 440 x 120 mm (height x width x depth) and has a net weight of 5.7 kg.
Finishes
The cabinet is vinyl-wrapped and is on sale in the Black Ash finish.
