Motorised TV lift with swivel, built to the size of the screen
PLS is a Future Automation TV lift that raises the screen out of a cabinet and turns it both ways, for anyone wanting to watch from several points in a room and hide the television when it is off.
Each mechanism is sized around the specified screen, from 32" to 60", so the lift matches the chosen television and takes up as little cabinet space as it can. The top flap works with the Future Automation drop & roll system: it drops into the cabinet, then turns 90° behind the screen, staying entirely hidden and leaving the cabinet with a clean finish.
Key features
- Made to measure for screens between 32" and 60"
- Top flap with the drop & roll system
- Motorised rotation of 180° to each side, storing as many as 6 programmable viewing positions
- Screen weight up to 50 kg, screen depth up to 130 mm
- Integrated cable management
- Separate control box, connected by a 3 m loom
- Declared noise level 59 dB
Control and integration
PLS responds to contact closure, IR and RS232 commands, and RF control can be added as an option. The stored viewing positions are recalled through the same commands, which lets the lift join a home control system. It runs on a 240 V or 110 V supply.
Environments
PLS is for indoor use. Future Automation builds it in its own facilities, in the USA and in Great Britain.
