Description
Audiophile power distributor with 6 independent outputs and advanced filtering for hi-fi and AV systems
Clean power and optimized distribution for an entire system
The IsoTek V5 Aquarius is a high-end power distribution amplifier designed to improve the quality of power supplied to complete hi-fi and home theater systems. This model adopts a structure with 6 independent filter networks , thus effectively reducing Common Mode noise , Differential Mode noise and cross-contamination between connected components. Compared to the previous generation, IsoTek claims a completely revised electrical architecture with a 35% increase in copper loading on the PCB and at least 25% improvement in Direct Current Resistance .
Two high current and four medium current outputs
The V5 Aquarius offers 6 total outlets + System Link , divided into 4 medium current outputs dedicated to sources, streamers, DACs and front-end components, and 2 high current outputs designed for amplifiers, active subwoofers, active speakers and devices with higher current demands. The four medium current outlets are 6A and reach up to 1,380 W total at 230 V or 690 W at 115 V , while the two high current 16A outlets can deliver up to 3,680 W at 230 V or 1,840 W at 115 V. IsoTek also integrates the Adaptive Gating system on the dedicated source outputs and a practical System Link for expanding the system while maintaining the star-earth configuration.
High protection, effective filtering and high-level construction
Highlights of the product include 65dB RFI reduction , 81,000A instantaneous and 40,000A continuous surge protection, as well as a fully star-earthed network. Internal wiring uses silver-plated Ohno Continuous Cast copper with FEP Virtual Air Dielectric , while the unit is supplied with 1.5m IsoTek EVO3 Premier cable . Dimensions are 450 x 110 x 350mm and a claimed weight of 9.5kg , with UK, EU, US, AU and CH plugs available.
| Typology | Audiophile power distributor / mains filter |
| Number of sockets | 6 + System Link |
| Architecture | 6 independent filter networks |
| Type of exits | 4 medium current + 2 high current |
| Medium current outputs at 230 V | 4 x 6A (1,380 W total) |
| Medium current outputs at 115 V | 4 x 6A (690 W total) |
| High current outputs at 230 V | 2 x 16A (3,680 W total) |
| High current outputs at 115 V | 2 x 16A (1,840 W total) |
| RFI reduction | 65 dB |
| Overvoltage protection | 81,000 A instantaneous / 40,000 A continuous |
| Source output technology | Adaptive Gating |
| Grounding | Fully star-earthed |
| Internal wiring | Silver-Plated OCC Copper with FEP Virtual Air Dielectric |
| Network input | 16A IEC C20 |
| Supported mains voltage | 100 – 240 V |
| Supported network frequency | 50 – 60 Hz |
| Dimensions (W x H x D) | 450 x 110 x 350 mm |
| Weight | 9.5 kg |
| Cable included | IsoTek EVO3 Premier 1.5 m |
| Standard sockets available | UK, EU, US, AU, CH |
